“One Leg Chain Sling, Master Link Ring on Top and Legs ending in Eye Self Locking Hook connected by Chain Connector / Hammer Lock / Coupling Link”. Safe and Secure offers high-quality JB Lifting Grade 80 and Grade 100 Alloy Chain Slings (from 7mm to 32mm in diameter) and a wide range of chain components and fittings as well.
ONE-LEG CHAIN SLING WITH EYE SELF LOCKING HOOK
Safe and Secure (SSTC) offers A Leg Chain Sling With Eye Self Locking Hook JB Lifting components made from special quenched and tempered alloy steel, a guarantee for very high strength, low weight, high wear resistance, and long life. All Lifting components are uniformly marked with equivalent chain size, grade, manufacturer’s designation, and name for identification. The Grade 80 Chains offer not only value for money but also quality and longevity of service.
- Standard: EN818
- Material: Alloy Steel
- Grade: 80
- Safety Factor: 4:1
- Construction: Quenched & Tempered
- Proof Load: 2.5 times of SWL
- Finish: Self Coloured
Specifications:-
| ItemCode(s) | CHAIN DIAMETER | CAPACITY IN DIFFERENT SHAPE (SWL) | WEIGHT | Chain Weight | |||
| Vertical | Choker | Basket | |||||
| mm | Inch | (Ton) | (Ton) | (Ton) | (kgm) | (kg) | |
| SCA-SOESLH-7 | 7 | 9/32 | 1.5 | 1.2 | 3 | 1.88 | 0.79 |
| SCA-SOESLH-8 | 8 | 5/16 | 2 | 1.6 | 4 | 3.07 | 1.38 |
| SCA-SOESLH-10 | 10 | 3/8 | 3.2 | 2.5 | 6.4 | 5.96 | 2.2 |
| SCA-SOESLH-13 | 13 | 1/2 | 5.3 | 4.3 | 10.6 | 9.03 | 3.1 |
| SCA-SOESLH-16 | 16 | 5/8 | 8 | 6.4 | 16 | 14.25 | 5.63 |
| SCA-SOESLH-20 | 20 | 3/4 | 12.5 | 10 | 25 | 18.96 | 8.6 |
| SCA-SOESLH-22 | 22 | 7/8 | 15 | 12 | 30 | 35.51 | 10.2 |
| SCA-SOESLH-26 | 26 | 1 | 21.2 | 16.9 | 42.4 | 65.28 | 14.87 |
| SCA-SOESLH-32 | 32 | 1-1/4 | 31.5 | 25.2 | 63 | 75.73 | 21 |
Please Contact Us for your inquiry!
Precautions & FAQs| Diameter (mm) | 7mm, 8mm, 10mm, 13mm, 16mm, 20mm, 22mm, 26mm, 32mm |
|---|---|
| Length (Meter) | 1 Meter, 2 Meter, 3 Meter, 4 Meter, 5 Meter, 6 Meter, 8 Meter, 10 Meter, 12 Meter |
